Accuphase E-4000 Integrated Stereo Amplifier

The E-4000 integrated amplifier has been developed from various separate amplifier technologies. Its preamplifier section features AAVA technology combined with ANCC, allowing for volume adjustments that preserve a high level of vibrancy. The power amplifier section employs balanced transmission, utilizing the instrumentation amplifier principle to achieve maximum noise suppression. The E-4000 is equipped with a four-fold parallel push-pull configuration of power transistors, driven in Class AB in the output stage, to extract every bit of potential from the speakers and create soundscapes rich in subtlety.

• Revolutionary AAVA volume control
• Four-fold parallel push-pull configuration of power transistors driven in Class AB
• High power output of 180 watts into 8 ohms / 260 watts into 4 ohms
• Power amplification stage configured as instrumentation amplifier
• High damping factor of 800
• Strong power supply with massive high-efficiency toroidal transformer
• High-voltage, large filtering capacitors
• Protection circuitry using MOS-FET switches

Specification:
Dimension: Width 465 mm (18.3”) × Height 181 mm (7.1”) × Depth 428 mm (16.9”)
Net Weight: 24.9 kg (54.9 lbs)
