Eversolo DMP-A10
Masterpiece Flagship
Experience Heavenly Sound
DMP-A10 is a flagship all-in-one streaming decoder with excellent audio quality and diverse functions, bringing users an immersive listening experience. It uses advanced electrical isolation technology, high-performance DAC chips and professional correction systems to ensure the purity and accuracy of audio signals. In addition, it supports direct streaming of multiple music services and provides a wealth of expansion options to meet users' various music needs.
Carefully crafted like a work of art
The DMP-A10 case blends modern aesthetics with romanticism and is precision engineered using CNC technology. With a length of 430 mm, it blends seamlessly into high-end sound systems, combining functionality and elegance.
Combination of precision and purity
The DMP-A10 features a high-speed electrical isolation system that isolates noise and interference from different circuit boards. Complete physical isolation eliminates possible interference to the audio circuit during system circuit signal transmission, ensuring that the audio signal remains pure and uninterrupted. The display panel also features a shielded design, resulting in excellent audio clarity and precision for an unparalleled listening experience.
Isolated USB Audio for Ultimate Precision
By utilizing advanced electrical isolation circuitry, the DMP-A10 minimizes interference and ground loop issues from noisy power supplies when connecting external DACs and USB devices. Utilizing iCoupler ® technology, it transmits clock signals and data to the isolated side in the correct time sequence and then resynchronizes to maintain consistency. This ensures that USB signals are transmitted with high fidelity, reducing timing errors and maintaining signal accuracy.
Dual bass output
The DMP-A10 features two subwoofer output ports, allowing you to connect a single or dual subwoofer if desired, or even deactivate the subwoofer function. MIXER and STEREO modes can be easily switched, and subwoofer gain, crossover frequency and delay can be adjusted independently. (*The subwoofer function is only applicable to PCM signals below 192KHz.)
OCXO clock system
Eversolo's temperature control technology tailored for the OCXO clock system ensures that the two audio crystal oscillators (45.1584MHz and 49.152MHz) operate at a constant optimal temperature point, thereby eliminating frequency fluctuations caused by temperature changes and providing extremely low phase noise. Each oscillator undergoes a rigorous testing process. Therefore, when the jitter level is lower than 50fs, a more accurate clock signal can be provided to the sound system, thereby increasing the clarity, detail and air of the sound.
SFP Fiber Network Interface SFP fiber network interface
In order to eliminate the interference of high-frequency noise in network switches and other network equipment, the DMP-A10 introduces an SFP optical port, allowing users to connect the DMP-A10 to the local network through optical fiber. In this case, clearer audio can be transmitted without the need for an electrical connection between a network switch and the DMP-A10. Traditional RJ45 Ethernet connections are also supported for easy integration. (*SFP module needs to be purchased separately.)
Crystal clear audio
The audio terminals of DMP-A10 are made of silver-plated single crystal copper wire, which has excellent conductivity and signal transmission performance, bringing additional benefits to the audio, making it clearer, more transparent and rich in details.
room correction technology
With Eversolo Digital Room Correction, the DMP-A10 uses high-precision microphones to analyze your listening environment and adjust sound frequencies through complex algorithms to eliminate acoustic problems. A more immersive and lifelike listening experience tailored to your space
digital to digital converter
DMP-A10 supports DDC (Digital to Digital Converter) function. Digital signals from USB audio input, coaxial/optical input, and ARC input can be output as SPDIF signals or analog signals after various EQ adjustments. In addition, the analog signal input can be captured by a high-standard ADC (up to 192kHz) and then output as a SPDIF signal or an EQ-adjusted analog signal.
Strong power, ultra-low noise
In order to further improve the purity of sound, DMP-A10 uses dual power supplies with ultra-low background noise to provide stable power output for digital systems and analog audio circuits. Analog audio power ripple can be reduced to less than 30μVrms, creating a quiet and pure listening environment. In addition, it uses patented smart switch technology for linear power supply voltage input, making it compatible with global voltages without flipping a switch.
Fully balanced analog preamplifier circuit
DMP-A10 is equipped with a high-performance fully balanced pre-circuit and supports XLR/RCA analog input. It has +10dB analog gain and R-2R analog volume control to ensure ultra-low noise and distortion, providing better signal-to-noise ratio, dynamic range and other performance indicators.
Powered by EOS
The Eversolo Original Sample Rate Audio Engine (EOS) ensures native sample rate output from your favorite music applications. The DMP-A10 bypasses SRC restrictions and can route audio to the speakers without any changes. It also supports direct output from third-party applications such as Apple Music to achieve high-resolution lossless playback.
Stream your favorite music services
Enjoy direct access to major music services on the DMP-A10. Whether it's TIDAL, Qobuz, Amazon Music, Tuneln, IDAGIO, Radio Paradise, SoundCloud, Calm Radio, KKbox or Highresaudio, the DMP-A10 has it all. (More music services will be added in the future.)
Amazing volume control
A fully balanced analog volume adjustment network composed of precision resistors and relays achieves precise volume control and effectively suppresses distortion and noise in analog signals. It also features volume protection, which automatically reduces excessive volume to a specified safe level when activating or switching inputs. The incorporation of the R2R analog volume control ensures that the DAC can continuously operate in optimal bypass conditions.
Stylish VU watch
DMP-A10 has a multi-dynamic VU meter tailored for audiophiles, with both music and appearance!
wireless streaming hub
The DMP-A10 supports Roon Ready*, Tidal Connect, Squeeze Connect and DLNA protocols to serve as the streaming center of your home. No matter where you are in your home, sit back and enjoy.
Family Music Center
In addition to two high-speed USB 3.0 ports and two SSD slots, the DMP-A10 also supports NFS, SMB, UPnP and more sharing protocols, allowing you to easily transfer media from NAS devices or network drives. Even high-bitrate files such as DSD512 master recordings can be played back without stuttering. Additionally, it supports loading and playing music from WebDAV, Plex, Emby and Jellyfin.
local storage expansion
The two M.2 NVMe SSD slots at the bottom can support up to 4TB*2 storage expansion. Convenient installation and better heat dissipation design provide fast and stable support for high-quality local playback; external storage devices can also be connected through the USB 3.0 port.
Control at your fingertips
The DMP-A10 has a variety of control options. In addition to the touch screen and mobile control app, the device also comes with Bluetooth and infrared remote controls. Made of one-piece alloy material, this remote has a refined, streamlined appearance that fits your hand perfectly, allowing you to control your music with ease.
Bigger and better
The upgraded control panel features a larger touchscreen display for an immersive user experience. DMP-A10's fully intelligent music interface has a mobile device-like operating experience, is intuitive and smooth, and provides a better viewing experience such as a larger album cover display. It's designed not only for superior sound, but also for luxurious visual enjoyment.
Global music search
With the DMP-A10, you can search multiple music services at once, making it easier than ever to find your favorite tracks, seamlessly connecting to all your music services. *Note: Comprehensive music service requires a login account to perform global search.
Personalized music management Eversolo provides a comprehensive and beautiful local music library. You can add music files from a local drive or network storage device, and the library will automatically obtain available music metadata, matching album covers, artist information, and CUE files from the cloud. You can create custom playlists to organize your music by different tags such as genre, sample rate, album, and artist.
Perfect sound quality anytime, anywhere
The DMP-A10 features a 10-band PEQ (parametric equalizer) module that allows precise adjustments to specific frequencies, gain and Q-factor to significantly enhance sound quality. In different listening environments, sound may be reflected and absorbed differently, causing certain frequencies to be too strong or too weak. By using PEQ fine-tuning, the DMP-A10 ensures that the sound remains natural and pleasant. In addition, it supports FIR filter import, loudness adjustment and dynamic compression.
Maintain eternal quality
The DMP-A10 allows CD playback and ripping by connecting a USB optical drive. Adopting a unique data verification and error correction mechanism to ensure the lossless preservation of CD audio data. The CD app contains a smart algorithm to obtain album and track names (for officially released CDs), automatically generating album and artist information.
Note: Metadata retrieval is not guaranteed for all CDs. Online databases may not always have up-to-date information.
